Viewing Azure Site to Site VPN Logs in Log Analytics

Published On: 2021-11-15By:

Recently I needed to view the logs from an Azure Site to Site VPN to see why it wasn’t working as expected. When Azure Site to Site VPNs aren’t working as expected the GUI falls apart quickly for troubleshooting.

Log Analytics is where this problem gets solved. Log Analytics is going to allow you to see basically everything that the Azure Network Gateway is doing. Setting the feed up to Log Analytics isn’t as straightforward as it could be, but it is documented in this post.

In order to view the data, open the Azure Network Gateway in the Azure Portal and find the “Logs” option under “Monitoring” on the menu on the left. This will open the Log Analytics query editor. Cancel out of the sample queries that it gives you access to.

The following query will show you the messages that you are receiving from the IKE Diagnostics.

AzureDiagnostics
| where TimeGenerated > ago(24h)
| where Category == “IKEDiagnosticLog”
| project TimeGenerated, Resource, Message
| order by TimeGenerated desc

The following query will show you the messages that are being logged by the site-to-site VPN Tunnel itself.

AzureDiagnostics
| where TimeGenerated > ago(24h)
| where Category == “TunnelDiagnosticLog”
| project TimeGenerated, Resource, stateChangeReason_s
| order by TimeGenerated desc

With the information provided from these queries you should be able to troubleshoot just about any VPN issue that you are seeing when setting up the Azure Site to Site VPN.

Denny

Contact the Author | Contact DCAC

Setting up Azure Network Gateway Logging

Published On: 2021-11-08By:

If you’ve ever set up an Azure Network Gateway for Site to Site or Person to Site VPNing you’ve probably wanted to be able to see logging from the gateway. In the Azure portal, you can see a Logs option, but all it does is tell you to set up log analytics and the link that it gives you is … less than helpful.

In order to set up Log Analytics for your Azure Network Gateway (or other Azure resources that don’t have a direct way to configure diagnostics), you need to configure the Azure Monitor. To find the Azure Monitor search for “monitor” in the search bar within the Azure Portal. Once you find Monitor click on the Monitor option.

From here scroll down on the menu and find the settings section. In this section, you’ll find a “Diagnostic Settings” option. Select “Diagnostic Settings”.

This will bring up a screen that includes a subscription selector, a resource group selector, and a resource type selector. Select the subscription that contains the resource, and the page will refresh with the resources in that subscription. If needed filter down the list based on the resource group and resource type. Once you have found the resource you wish to add to Log Analytics, select the resource and another page will open.

On the new page, you’ll see that there are no diagnostic settings defined. Click on the “Add diagnostic settings” link and a new page will open. This new page will allow you to select the Log Analytics workspace that you will send the data to as well as the kind of data that you want to be logged in addition to a same for the settings.

Set the name, the kind of data that you want to send to Log Analytics, and the Log Analytics workspace that you want to send the data to.

Click OK to save the settings, and if needed close the window (it doesn’t always close in my experience). At this point (or in a few minutes) the Logs option on the resource should work correctly and allow you to view the data in Log Analytics related to the resource.

Denny

Contact the Author | Contact DCAC

Power BI, Maps, and Publish to Web

Published On: 2021-10-14By:

October 2021 is mapping month over at Workout Wednesday for Power BI. As part of our challenges, we build a sample report and use the Publish to Web functionality to share it on the website. While this has worked well all year, there are some visuals, including maps, that do not support or require a different license for use with Publish to Web.

It’s frustrating to build a Power BI report that you plan to share, only to find that you can’t share it. So I thought it would be helpful to consolidate what I have found about the various map visuals and their support of Publish to Web.

Disclaimer: This information is correct as of October 14, 2021. This could change over time. This is not an exhaustive list of all the map visuals available for Power BI.

Map Visuals

6 map visuals on a power bi report: a bubble map, filled map, shape map, ArcGIS map, Azure Map, Mapbox map.
Examples of the 6 map visuals tested with Publish to Web

Note: I also tested several other AppSource visuals, but they failed to render in Power BI desktop. I may update this post if they start working again.

I hope this helps you plan your visuals when you need to publicly share a report that contains a map.

Contact the Author | Contact DCAC

Connect Excel to a Power BI Dataset in a Premium Workspace with a B2B User

Published On: 2021-09-30By:

Power BI offers the ability for users who have access to a dataset in the Power BI service (PowerBI.com) to connect to the dataset using Excel. Normally, this feature is referred to as Analyze in Excel. Once you connect Excel to your dataset, you can create Pivot Table reports or use Cube Functions.

There are currently limitations that mean this functionality isn’t supported for B2B (external) users. An external user is an Azure AD user that is based in another tenant and has been guested into the local AAD tenant. If you go to your dataset in PowerBI.com. choose Analyze in Excel, and then try to open the downloaded file and connect to the dataset, you will be met with connection errors.

But if you have your dataset in a workspace backed by Premium Per User or Premium capacity, you can use the XMLA endpoint to connect, even if you are using a B2B user!

Instead of using the Analyze in Excel functionality, you can connect to your dataset as if it were Analysis Services, using the XMLA endpoint. B2B users just need to make one adjustment to the server name they enter to make this work.

In Excel, locate the Get Data button. Select From Database and then From Analysis Services.

Get Data menu in Excel with the options From Database and From Analysis Services selected.
Connecting to a Power BI dataset using the XMLA endpoint in Excel is done in a similar manner as connecting to an Analysis Services database

Open a browser window and go to the settings of the Power BI workspace that contains the dataset to which you want to connect.

Settings for a Power BI workspace called Demo Reports.
Power BI Premium workspaces of any kind should have the workspace connection string listed in the settings pane

If your workspace is backed by Premium capacity, you will be able to see this in the settings and the workspace connection will be available for you to copy. If you are a member user (not external) you could copy this info into the Server Name box of the Data Connection Wizard and go on your way.

If you are a B2B user, you need to make an adjustment as noted in Microsoft Docs. You need to replace “myorg” in the workspace connection with your primary domain name. If you have access to the Azure portal, you can find the primary domain name on the overview page for the Azure Active Directory.

Overview page in the Azure Portal for Azure Active Directory with the Primary Domain circled under basic information.
The tenant UPN, also called primary domain can be found in the Azure Portal on the AAD overview page

So if the workspace connection from the Power BI service is:
powerbi://api.powerbi.com/v1.0/myorg/Demo%20Reports

And your primary domain is:
mysupercooldomain.com

Then you would change the workspace connection to:

powerbi://api.powerbi.com/v1.0/mysupercooldomain.com/Demo%20Reports

Once you have populated the server name with the workspace connection string, change the logon credentials to “Use the following user name and password” but leave the credentials blank. Once you select the Next button, you will be prompted for your Azure credentials.

Then you will be able to select the desired dataset from the workspace and be on your way to making connected Excel reports.

Contact the Author | Contact DCAC
